Casement Window Secondary Glazing

Built specifically for casement primary windows

Casement windows swing open on side hinges, so a sliding secondary unit blocks the handle. Our hinged casement units mirror the primary opening: unlock, swing the secondary panel clear, then open the original as normal for ventilation, cleaning or emergency egress.

Built for security and access

Our hinged casement units open like a door, giving you full unobstructed access to the original window for cleaning, ventilation and emergency egress. Optional multi-point locks and key-locking handles are available on every unit.

• Left- or right-hand hinge
• Optional key-locking handle
• Approved for fire-escape openings
• Full unobstructed access to primary window

Heavy-duty and slim-line profiles

Choose the standard heavy-duty profile for demanding commercial or exposed installations, or our Vision HD slim-line profile for a discreet finish in period homes. Vision HD accepts sealed double-glazed units up to 28mm — the deepest DGU capacity in the market.

• Vision HD accepts up to 28mm DGU
• Slim sightlines for period property
• Heavy-duty option for commercial
• 200+ RAL colours available

Where hinged casement works best

Ideal for casement primary windows, fire-escape rooms, single small openings and any window that isn't practical for a sliding or lift-out solution. Commonly used in bedrooms, stairwells and commercial front-of-house.

How it operates

One or more casements hang on concealed or face fixed hinges within a slim outer frame, closing onto a continuous compression gasket and secured by an espagnolette or cockspur handle. Because the sash pulls tight onto a gasket rather than sliding past a brush seal, a hinged unit gives the best draught and acoustic seal of any openable system we fit. Top hung units are used at high level and over sinks, side hung for anything reachable.

What it suits

Fire escape windows, casement primaries with awkward handles, doors and door side lights, and any opening that has to be thrown wide quickly. The heavy duty variant takes a sealed double glazed unit up to 28mm, which makes it the option to specify when thermal performance is the priority rather than acoustics.

• Designated fire escape windows
• Doors, side lights and French doors
• Heavy duty version takes 28mm sealed units
• Slim line version for discreet sight lines

How it is fitted

The frame is templated and fixed into the reveal with the hinge side packed dead plumb, since a hinged sash will drop or spring open if the stile is out of true. Clearance into the room is checked at survey against radiators, window seats, blinds and curtain poles, because a casement needs swing space that a slider does not. Perimeter sealing is the same low modulus bead used across the range.

Cleaning and access to the original window

Open the casement and you have the whole opening, so cleaning both faces of the secondary glass and the original window is straightforward and needs no lifting. This is the easiest system in the range for a person who cannot handle a lift out panel, and the one we specify most often for elderly customers and for high use rooms.

• Full width access in one movement
• No lifting or panel storage
• Easy reach to primary window handles
• Restrictor stays available on request

Ventilation

Ventilation is unrestricted when open, and controlled by the handle when nearly closed: an espagnolette can be set on the night vent notch to leave a sealed but ventilated gap. Trickle vents can be fitted into the frame head where the primary window carried them. For fire escape openings we avoid any locking arrangement that needs a key from inside unless the customer specifically requests it and understands the escape implication.

Where it is the wrong choice

It is wrong where nothing can project into the room, such as behind a window seat, a deep sill of ornaments, a radiator shelf or a shutter box. It is wrong on very wide single openings, where a large hinged leaf becomes unwieldy and a horizontal slider is safer. And it is the wrong money on a window that never opens, where a lift out or fixed panel gives the same seal for less.
